H70 / C26000 / CuZn30 / C2600 Brass Bar-JiangSu QuanGang Metal Materials Co., Ltd

Copper bar



Home / Copper / Copper bar / H70 / C26000 / CuZn30 / C2600 Brass Bar

H70 / C26000 / CuZn30 / C2600 Brass Bar

sale@quansteel.com

8615335229905

Parameter

Chemical Composition

Mechanical Properties

Item	Brass bar,brass rod
Standard	ASTMB152,B187,B133,B301,B196,B441,B465,JISH3250-2006,GB/T4423-2007,etc
Diameter	3mm~800mm
Length	5.8m,6m,or as required
Package	Standard export seaworthy package,suit for all kinds of transport,or as required.
ContainerSize	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Price term	Ex-Work,FOB,CNF,CFR,CIF,etc
Application	Brass bar is widely used in boat building,War industry, Car industry and communicationindustry where the components need good wear proof and great corrosion resistance
Contact	If you have any question,please feel free to contact me .

Grade	Main components			Impurity components %		total impurities %
	Cu	Pb	Zn	Fe	Ni
HPb59-1	57-60	0.8-1.9	margin	≤0.5	≤1.0	≤1.0
HPb59-2	57.5-59.5	2.0-2.8	margin	≤0.5	--	≤1.2
HPb59-3	57.5-59.5	2.0-3.0	margin	≤0.5	≤0.5	≤1.2
HPb60-2	58-61	1.5-2.5	margin	≤0.3	-	-
HPb62-2	60-63	1.5-2.5	margin	≤0.15	-	-
HPb62-3	60-63	2.5-3.7	margin	≤0.35	-	-
HPb63-3	62-65	2.4-3.0	margin	≤0.1	≤0.5	≤0.75
	Main components %			Impurity components%
	Cu	Zn	Pb		Fe	Ni
H59	57-60	margin	≤0.5	≤0.3	≤0.5	≤1.0
HP62	57-60	margin	≤0.08	≤0.15	≤0.5	≤0.5
H65	63.5-68	margin	≤0.03	≤0.1	≤0.5	≤0.3
H68	67-70	margin	≤0.03	≤0.1	≤0.5	≤0.3
H70	68.5-71.5	margin	≤0.03	≤0.1	≤0.5	≤0.3
H80	79-81	margin	≤0.03	≤0.1	≤0.5	≤0.3
H85	84-86	margin	≤0.03	≤0.1	≤0.5	≤0.3
H90	88-91	margin	≤0.03	≤0.1	≤0.5	≤0.2
H96	95-97	margin	≤0.03	≤0.1	≤0.5	≤0.2

GB	DIN		EN		ISO	UNS	JIS
TU2	OF-Cu	2.004	Cu-OFE	CW009A	Cu-OF	C10100	C1011
-	SE-Cu	2.007	Cu-HCP	CW021A	-	C10300	-
-	SE-Cu	2.007	Cu-PHC	CW020A	-	C10300	-
T2	E-Cu58	2.0065	Cu-ETP	CW004A	Cu-ETP	C11000	C1100
TP2	SF-Cu	2.009	Cu-DHP	CW024A	Cu-DHP	C12200	C1220
-	SF-Cu	2.009	Cu-DHP	CW024A	Cu-DHP	C12200	C1220
-	SF-Cu	2.009	Cu-DHP	CW024A	Cu-DLP	C12200	C1220
TP1	SW-Cu	2.0076	Cu-DLP	CW023A	Cu-DLP	C12000	C1201
H96	CuZn5	2.022	CuZn5	CE500L	CuZn5	C21000	C2100
H90	CuZn10	2.023	CuZn10	CW501L	CuZn10	C22000	C2200
H85	CuZn15	2.024	CuZn15	CW502L	CuZn15	C23000	C2300
H80	CuZn20	2.025	CuZn20	CW503L	CuZn20	C24000	C2400
H70	CuZn30	2.0265	CuZn30	CW505L	CuZn30	C26000	C2600
H68	CuZn33	2.028	CuZn33	CW506L	CuZn35	C26800	C2680
H65	CuZn36	2.0335	CuZn36	CW507L	CuZn35	C27000	C2700
H63	CuZn37	2.0321	CuZn37	CW508L	CuZn37	C27200	C2720
HPb63-3	CuZn36Pb1.5	2.0331	CuZn35Pb1	CW600N	CuZn35Pb1	C34000	C3501
HPb63-3	CuZn36Pb1.5	2.0331	CuZn35Pb2	CW601N	CuZn34Pb2	C34200	-
H62	CuZn40	2.036	CuZn40	CW509N	CuZn40	C28000	C3712
H60	CuZn38Pb1.5	2.0371	CuZn38Pb2	CW608N	CuZn37Pb2	C35000	-
HPb63-3	CuZn36Pb3	2.0375	CuZn36Pb3	CW603N	CuZn36Pb3	C36000	C3601
HPb59-1	CuZn39Pb2	2.038	CuZn39Pb2	CW612N	CuZn38Pb2	C37700	C3771
HPb58-2.5	CuZn39Pb3	2.0401	CuZn39Pb3	CW614N	CuZn39Pb3	C38500	C3603
-	CuZn40Pb2	2.0402	CuZn40Pb2	CW617N	CuZn40Pb2	C38000	C3771
-	CuZn28Sn1	2.047	CuZn28Sn1As	CW706R	CuZn28Sn1	C68800	C4430
-	CuZn31Si1	2.049	CuZn31Si1	CW708R	CuZn31Si1	C44300	-
-	CuZn20Al2	2.046	CuZn20Al2As	CW702R	CuZn20Al2	C68700	C6870
QSn4-0.3	CuSn4	2.1016	CuSn4	CW450K	CuSn4	C51100	C5111
-	CuSn5	2.1018	CuSn5	CW451K	CuSn5	C51000	C5102
QSn6.5-0.1	CuSn6	2.102	CuSn6	CW452K	CuSn6	C51900	C5191
QSn8-0.3	CuSn8	2.103	CuSn8	CW453K	CuSn8	C52100	C5210
BZn12-24	CuNi12Zn24	2.073	CuNi12Zn24	CW403J	CuNi12Zn24	C75700	-
BZn12-26	CuNi18Zn27	2.0742	CuNi18Zn27	CW410J	CuNi18Zn27	C77000	C7701
BZn18-18	CuNi18Zn20	2.074	CuNi18Zn20	CW409J	CuNi18Zn20	C76400	C7521
-	CuNi10Fe1Mn	2.0872	CuNi10Fe1Mn	CW352H	CuNi10Fe1Mn	C70600	C7060
-	CuNi30Mn1Fe	2.882	CuNi30Mn1Fe	CW354H	CuNi30Mn1Fe	C71500	C7150

PRODUCT DISPLAY

STEEL STANDARDS AND GRADES

GB	DIN		EN		ISO	UNS	JIS
TU2	OF-Cu	2.0040	Cu-OFE	CW009A	Cu-OF	C10100	C1011
-	SE-Cu	2.0070	Cu-HCP	CW021A	-	C10300	-
-	SE-Cu	2.0070	Cu-PHC	CW020A	-	C10300	-
T2	E-Cu58	2.0065	Cu-ETP	CW004A	Cu-ETP	C11000	C1100
TP2	SF-Cu	2.0090	Cu-DHP	CW024A	Cu-DHP	C12200	C1220
-	SF-Cu	2.0090	Cu-DHP	CW024A	Cu-DHP	C12200	C1220
-	SF-Cu	2.0090	Cu-DHP	CW024A	Cu-DLP	C12200	C1220
TPI	SW-Cu	2.0076	Cu-DLP	CW023A	Cu-DLP	C12000	C1201
H96	CuZn5	2.0220	CuZn5	CE500L	CuZn5	C21000	C2100
H90	CuZn10	2.0230	CuZn10	CW501L	CuZn10	C22000	C2200
H85	CuZn15	2.0240	CuZn15	CW502L	CuZn15	C23000	C2300
H80	CuZn20	2.0250	CuZn20	CW503L	CuZn20	C24000	C2400
H70	CuZn30	2.0265	CuZn30	CW505L	CuZn30	C26000	C2600
H68	CuZn33	2.0280	CuZn33	CW506L	CuZn35	C26800	C2680
H65	CuZn36	2.0335	CuZn36	CW507L	CuZn35	C27000	C2700
H63	CuZn37	2.0321	CuZn37	CW508L	CuZn37	C27200	C2720
HPb63-3	CuZn36Pb1.5	2.0331	CuZn35Pb1	CW600N	CuZn35Pb1	C34000	C3501
HPb63-3	CuZn36Pb1.5	2.0331	CuZn35Pb2	CW601N	CuZn34Pb2	C34200	-
H62	CuZn40	2.0360	CuZn40	CW509N	CuZn40	C28000	C3712
H60	CuZn38Pb1.5	2.0371	CuZn38Pb2	CW608N	CuZn37Pb2	C35000	-
HPb63-3	CuZn36Pb3	2.0375	CuZn36Pb3	CW603N	CuZn36Pb3	C36000	C3601
HPb59-1	CuZn39Pb2	2.0380	CuZn39Pb2	CW612N	CuZn38Pb2	C37700	C3771
HPb58-2.5	CuZn39Pb3	2.0401	CuZn39Pb3	CW614N	CuZn39Pb3	C38500	C3603
-	CuZn40Pb2	2.0402	CuZn40Pb2	CW617N	CuZn40Pb2	C38000	C3771
-	CuZn28Sn1	2.0470	CuZn28SnlAs	CW706R	CuZn28Sn1	C68800	C4430
-	CuZn31Si1	2.0490	CuZn31Sil	CW708R	CuZn31Sil	C44300	-
-	CuZn20Al2	2.0460	CuZn20Al2As	CW702R	CuZn20Al2	C68700	C6870
QSn4-0.3	CuSn4	2.1016	CuSn4	CW450K	CuSn4	C51100	C5111
-	CuSn5	2.1018	CuSn5	CW451K	CuSn5	C51000	C5102
QSn6.5-0.1	CuSn6	2.1020	CuSn6	CW452K	CuSn6	C51900	C5191
QSn8-0.3	CuSn8	2.1030	CuSn8	CW453K	CuSn8	C52100	C5210
BZn12-24	CuNi12Zn24	2.0730	CuNi12Zn24	CW403J	CuNi12Zn24	C75700	-
BZn12-26	CuNi18Zn27	2.0742	CuNi18Zn27	CW410J	CuNi18Zn27	C77000	C7701
BZn18-18	CuNi18Zn20	2.0740	CuNi18Zn20	CW409J	CuNi18Zn20	C76400	C7521
-	CuNi10Fe1Mn	2.0872	CuNi10Fe1Mn	CW352H	CuNi10Fe1Mn	C70600	C7060
-	CuNi30MnlFe	2.8820	CuNi30Mn1Fe	CW354H	CuNi30MnlFe	C71500	C7150

ABOUT US

Key products such as stainless steel, carbon steel, copper, aluminum, and alloys have entered key industries such as petroleum, petrochemicals, railways, automobiles, shipbuilding, containers, and coinage, and are applied in key fields such as high-speed rail, sports venues, and nuclear power. Its rapid and stable development cannot be achieved without the company's high-quality talent team and advanced management model. At the same time, in the spirit of "quality survival, innovative development", we strive to strive for excellence in every detail, achieving a win-win situation for both the company's interests and customer interests. The company is committed to building a resource saving and environmentally friendly modern enterprise, and is committed to building a world-class, high-quality research and development and production base for stainless steel and special alloy materials, becoming the first choice for customers.

WORKSHOP PACKAGING

Packaging and loading:

Packaging: According to customers' needs, use wrapping paper. If the transportation period exceeds 10 days or encounters special climate, we will use waterproof packaging and add plastic film to prevent moisture, water and rust.

Loading: We use the wooden pallet,triangular wood to fix the coil,and the steel wire rope to hold on the both side. That can prevent from the crush injury effectively.

FAQ

Q1:Do you provide samples? Is it free or extra?
A1:Yes, we can provide samples free of charge and the customer will pay the freight.
Q2:What if I don't have export experience ?
A2:We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.
Q3:How long is your lead time?
A3:If it is in stock, it is usually 5-10 days. Or, if there is no inventory, 15 days, depending on the quantity.
Q4:What are your terms of payment?
A4:30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100%.Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A.
Q5:How is your technical support?
A5:We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you call anytime.
